1. Power: AC 230 V-50Hz or 120V -60Hz

2. Input Power :160VA or 180VA
3. Rate Current: 0.7A or 1.5A
4. Max Capacity of Medicine cup: 6ml (cc)
5. Average Nebulization Rate: ≥0.18ml/min

6.Mode of Operation: continuous ＞24 hours
7.Max Working Pressure : ≥35Psi ( 345Kpa; 3.5 Bar )
8.Operation Pressure Range: 9-16Psi(62-110Kpa; 0.6-1.1 Bar)
9. Liter Operation flow: 5-8 LPM

10.Noise: ≤58dB(A) ( at 1 meter distance )
11. MMAD: ≦3.0um (0.9% saline/ tested by Cascade Impactor)
12.Unit Size: 230 X 150 X 190 MM

13.Unit Weight: 1.42 KGS

14.Operation Condition: ﹢5℃ to ﹢40℃, 10% RH to 93% RH

15.Suggested Applications : Hospital, clinic, atomizer room, nursing home, personal homecare.

Packing :

-Color gift box+ sponge inner support+Instruction manual

-Carton size: 38.2x 38.2 x50.4 cm  (8pcs /carton )

-Net Weight : 14.5KGS   Gross Weight: 15.2kg /carton

-1X 20″FT Container :3040PCS

1.Power: AC 230 V-50Hz or 120V -60Hz

2.Input Power: 160VA or 180VA Max

3.Rate Current: 0.7A or 1.5A

4.Operation Pressure Range: 9-16 psi (62-110kPa)

5..Operating flow range: 5-8 LPM

6.Max Pressure: ≥35 psi(241kPa)

7.Nebulization Rate: 0.2mL/min～0.6mL/min

8.Particle size (MMAD):2.4μm

9.Noise: ≤58 dB(A) (at 1 meter distance)

10.Max Capacity of Medicine cup: 6mL(cc)

11.Residual volume≤1.0ml

12..Operation Condition: +5℃ to + 40℃，30% R.H. to 85% R.H.

13.Transportation and storage conditions:-20℃~60℃,10%R.H.~93%R.H

14.Operating atmospheric pressure range:70～106 kPa

15.uint size 220*165*90mm

16.unit weight: 1.13KG

packing

color giftbox +spnge inner support +instruction manual

carton size 38.2*38.2*50.4cm 8pc/carton

net weight 14.5kgs

gross weight 15.2kgs

1*20FT container :3040pcs
