-Effective medication delivery
-Operates smoothly and quietly
- Specification
- Detail description
1.Input Power: 100-240 VAC/50/60Hz, 18W
4.Operation Pressure Range: 9-16 psi (62-110kPa)
5..Operating flow range: 5-8 LPM
6.Max Pressure: ≥35 psi(241kPa)
7.Nebulization Rate: 0.2mL/min~0.6mL/min
8.Particle size (MMAD):2.4μm
9.Noise: ≤58 dB(A) (at 1 meter distance)
10.Max Capacity of Medicine cup: 6mL(cc)
11.Residual volume≤1.0ml
12..Operation Condition: +5℃ to + 40℃ (41oF~104oF), 15% R.H. to 95% R.H.
13.Transportation and storage conditions:-20℃~60℃(-4oF~140oF), 10%R.H.~93%R.H
14.Operating atmospheric pressure range:70~106 kPa
Packing :
-Carton size: 54.5 x 20.0 x 40.0CM (12pcs/ carton)
-Net Weight : 10.0 KG Gross Weight: 10.6 KG
-1X 20″FT Container : 7704pcs
